F570 for Industrial Applications

With planetary gearbox for liquids up to 80,000 cPs max

  • Branch: Industry
  • Branch: Surface technology
  • Branch: Petrochemistry
  • Branch: Agriculture
  • Branch: Water treatment
  • Branch: Paints and lacquers
  • Branch: Chemistry

The FLUX VISCOPOWER F570 industrial progressive cavity pump with planetary gearbox is suitable to pump thin to high viscosity liquids. This positive displacement pump works smoothly at a constant pressure and ensures a gentle, pulsation-free pumping. The pumps are portable for mobile use and can also be used in fixed installations. With only a few components used for assembly, the pump can be easily dismantled, cleaned and serviced.
  • Application areas: Atex

Product attributes

  • Positive displacement pump that offers smooth pumping and with very little shear
  • Intuitive and quick to disassemble and clean
  • Gear ratio two-stage 1:16 or single stage 1:7
  • Comprehensive modular system for ease of maintenance
  • Wide range of viscosity can be covered
  • Transfer rate is maintained at constant pressure
  • High efficiency pumping
  • Available with ATEX certification for use in hazardous area
  • Can be used in horizontal applications
  • Pump/shaft/rotor can be dismantled
  • 100% Made in Germany

Benefits

  • Flow Rate: max 21.9 GPM (83 l/min)
  • Delivery Pressure: max 217 PSIG (15 bar)
  • Viscosity: 1 - 80,000 cPs
  • Outer Tube Diameter: 53 mm
  • Standard Immersion Lengths: 27, 39, 47, 60 in (700, 1000, 1200, 1500 mm)
  • Materials of Construction: Stainless Steel
  • Electropolish: 1.0 μ m Ra
  • Temperatures to 248°F (120°C)
  • Stator materials: PTFE, NBR white, FKM
  • Seal: SiC/SiC open mechanical seal or closed mechanical seal
  • Containers: 55 Gal Drums, totes, IBCs
